(1) QD80 Light Stationary Belt Conveyor Compared with TDI type, QD80 Light Stationary Belt Conveyor has a thinner belt and lighter load, with a transportation distance of no more than 100m and a motor capacity of no more than 22kw. It belongs to a high-strength belt conveyor.
(2) DX steel rope core belt conveyor, there are parallel thin steel ropes in the belt core of the conveyor belt, and a conveyor can travel up to several kilometers to dozens of kilometers.
(3) U-shaped belt conveyor, also known as trough belt conveyor, its obvious feature is to increase the trough idler angle of ordinary belt conveyor from 30 ° ~ 45 " to 90 ° to make the conveyor belt U-shaped. As a result, the belt is squeezed from the material, resulting in increased friction between the material and the belt, resulting in a conveyor inclination of up to 25°
(4) The tubular belt conveyor U-shaped belt conveyor belt is further grooved, and finally forms a round pipe, which is a tubular belt conveyor, because the conveyor belt is rolled into a round pipe, so it can realize closed conveying of materials, which can significantly reduce the pollution of powdery materials to the environment, and can realize bending operation.
(5) The conveyor belt of the air cushion belt conveyor does not run on the roller, but runs on the air film (air cushion), the roller is omitted, and the running roller is replaced by the immovable air chamber disc groove and air chamber with air holes, the moving parts are reduced, the total equivalent mass is reduced, the resistance is reduced, the efficiency is improved, and the operation is stable, and the belt speed can be improved. However, generally the lumpiness of the transported material does not exceed 300mm. In addition to using the idler roller to strongly press the conveyor belt into a trough shape, the method of increasing the logistics section can also change the conveyor belt itself, and make the carrying surface of the conveyor belt into a vertical side with a diaphragm. Generally, the vertical side cladding is made into a corrugated shape, so it is called a corrugated belt conveyor, which is suitable for large inclination angles, with an inclination angle of more than 30 ° and a maximum of 90 °.
(6) Pressed belt conveyor. The main advantages of this conveyor are: the maximum inclination angle of the conveyed materials can reach 90°, the running speed can reach 6m/s, the conveying capacity does not change with the change of inclination angle, and the closed conveying of loose materials and toxic materials can be realized. Its main disadvantages are complex structure, increased wear and tear of conveyor belts and large energy consumption.
(7) Steel rope traction belt conveyor
It is the product of the combination of endless rope transportation and belt transportation, which not only has the characteristics of high strength and flexible traction of steel rope, but also has the advantages of continuous and flexible belt transportation.
